Description

• Top quality copper boiler heated by multiple looped element.
• Pressure controlled by a triple contact pressure switch.
• Automatic water level system with a probe, electronic control unit and solenoid valve.
• The pressure of water and steam is separately controlled by brass safety valves.
• Standard clearance is 125mm. A raised group option is available at 150mm.
• Hot water and steam are released by rotating the valve handles on the solid brass valves. Flick lever operation valve handles are available as an option
• Brass bodied group with stainless shower plate, solenoid valve and high pressure pump.
• Thermosyphonic circulation ensures the group is kept constantly hot for perfect coffee making, with temperature control on each group.#
• Case, waste and cup tray are all made from stainless steel 304.
• Espresso tray and cup shield as standard on all machines.
• Easy clean stainless steel steam tubes.

Groups: 3

Cups Per / Hour: 360/600

Dimensions (mm): H 535 x W 785 x D 500

Weight: 84Kg

Boiler Capacity: 20L

Element Rating: 7.5kw/30Amp

Alternative Element Rating: single or 3 phase 9kw/45Amp

Hot Water Per Hour: 100L
